The volume can be adjusted at will;
Use high-quality materials;
Sturdy and durable, elegant and beautiful;
Easy and quick installation;
The material is Cold rolled steel/stainless steel optional
Support web page automatic upgrade, support web page to restore factory settings.
The waterproof level of the whole machine is IP66.
International CE/FCC/design standards.
Outdoor/Indoor use, anti-radiation, anti-interference.
Outdoor/Indoor use, high-strength lightning resistance 230-3000V.
High-strength anti-impact current 8, 20US 2.5KA.
Operating temperature: -25C - 75C.
With door lock, safe and convenient for maintenance.
POE power supply or AC230V/DC12V power supply optional.
1.VoIP SIP2.0
2. DTMF dialing
3.MTBF100000hours
4. MTTR: 2 hours
5.Auxiliary Contacts:1 Aux Output, dry contact
6. Rated load:0.3 A at 125 VAC; 1 A at 30 VDC
7.Contact Ratings. Load: Resistive load
8. Echo cancellation code:G.167/G.168
9.Rated carry current:1A
10. Max.switching current:1A
11.Max.switching voltage:125 VAC,60VDC
12. Audio Codes:G.711, G.722, G.729
13.IP Protocols:IPv4, TCP, UDP, TFTP, RTP, RTCP, DHCP, SIP
14.Call Control Signaling:VOIP SIP Info(DTMF), RFC 2833(DTMF)
15.Network:10/100 BaseTX Ethernet, RJ45 connectors, Cat5e or better
16.Power:Power over Ethernet, IEEE802.3af, Class 0 Local power, 12VDc,Idle 2W, Max 10W
17.Programming:Non-volatile flash memory programming and configuration through Web GUI
18.Management and Operation:DHCP and static IP, remote automatic software upgrade, centralized monitoring, status LED
19.LAN Protocols:Power over Ethernet(PoE,802.3af), WLAN(IEEE 802.3af), Network Access Control(IEEE 802.1x),STP(IEEE 802.1d), RSTP(IEEE 802.1d-2004)
